Infratec™ Sofia

Infratec™ Sofia brings the value of precision grain testing to grain receival sites of all sizes. Mobile, easy to use and aligned with the renowned Infratec™ analyser.

See how it works
Value Icon

Value

Accurate on-the-spot analysis. Mobile, robust and easy to use. Using Infratec™ database covering more than 20 years of harvest.
Sample Icon

Sample type

Wheat, barley, rapeseed/canola, corn, soy beans and more.
Parameter Icon

Parameters

Moisture, protein, oil and more.

Find out why 80% of all wheat traded globally is tested on an Infratec™

Get in touch with our specialists to discuss your potential business value with no strings attached. GET A QUOTE Let's talk

Features

  • Aligned with the official payment system

    The Infratec™ Sofia gives you a low-cost analyser offering reliable measurements aligned with the Infratec™ grain analyser. The Infratec is the official system used for payment by bulk grain handlers around the world and has a number of approvals for trade purposes.

  • Mobile and robust

    Mobile and robust, Infratec™ Sofia goes wherever you need it, making it an ideal solution where flexibility is important.

    The mobile analyser has the weight of 9 kg and runs on a 240vAC or 12vDC power supply. No grinding or sample-preparation is required.


  • ANN calibrations

    Infratec™ Sofia measurements are based on the same comprehensive data used to calibrate all Infratec™ instruments, acquired over 25 years of product development in collaboration with the grain industry. As new calibrations are released they are simply downloaded via the internet and transferred to the Infratec™ Sofia unit ensuring that your results are always accurate and reliable.

White Paper: Learn why rapid analysis with FOSS is superior to the reference method

The FOSS NIR calibration is now a global standard for measuring protein and moisture in whole grain of wheat and barley. In order to download this White Paper you need to submit the requested information and join our FOSS knowledge community. We will process your personal data in accordance with our Privacy Policy.

White Paper: Learn why rapid analysis with FOSS is superior to the reference method

The FOSS NIR calibration is now a global standard for measuring protein and moisture in whole grain of wheat and barley. In order to download this White Paper you need to submit the requested information and join our FOSS knowledge community. We will process your personal data in accordance with our Privacy Policy.

Please provide your first name
Please provide your last name
Please provide a valid email address
Please provide company name
Please provide your job title
Please provide country code
Please provide state code

Something went wrong!

Sorry, we were not able to send your form.

Technical specification


Feature Specification
Dimensions (W x D x H) 255 x 390 x 295 mm
Weight 9 kg
Measurement mode  Transmittance
Wavelength range 850 - 1050 nm
Analysis time 2 minutes and 40 seconds for 10 sub-samples
Detector Silicon Linear Array
Optical bandwidth 7 nm
Number of data points/scan 100
Absorbance range 1-4 AU

Installation requirements
Voltage supply 100-240 V AC *, frequency 50-60 Hz, Class 1, protective earth
Ambient temperature 0 - 45°C
Storage temperature -20 to 70°C
Ambient humidity
 < 93% RH, cyclic up to 100% RH
Mechanical environment Stationary when in use, in vehicles
EMC environment Light industry, industry and agricultural machines
*Mains supply voltage fluctuations not exceeding ±10% of the rated voltage.

Instrument management
FossManagerTM
